| 型 号Model | HX-03WT | HX-05WT | HX-08WT | HX-10WT | HX-12WT | HX-15WT | HX-20WT |
| 制冷量Cooling capacity | kW | 9.5 | 16.3 | 23.5 | 31.9 | 40.3 | 48.2 | 63.6 |
| Kcal/h | 8,170 | 14,020 | 20,210 | 27,430 | 34,650 | 41,460 | 54,690 |
| 功率Power | kW | 2.4 | 4.1 | 6 | 8.1 | 10.3 | 12.4 | 16.5 |
| 电源Voltage | 3P-380V-50HZ |
| 启动方式Start | 按序延时启动 Sequential delay start |
| 温控范围Operating temperature | 5℃-35℃ Adjustable from 5℃ to 35℃ |
| 控制精度Accuracy | ±1℃ |
| 载冷介质Cooling medium | 水Water（PH≈7） |
| 制冷剂Refrigerant | 型号 | R22（R407C、R404A、R134A） |
| Model |
| 制冷剂流量控制方式Control method | 外平衡感温式热力膨胀阀External balance temperature sensing thermal expansion valve |
| 冲注量Filling amount | Kg | 1.5 | 2.5 | 4 | 5 | 6.2 | 7.5 | 10.5 |
| 压缩机Compressor | 类型Type | 先进全封闭涡旋式或活塞式Fully enclosed vortex type or spring-piston |
| 启动方式启动方式Start type | 按序延时启动Sequential delay start |
| 输入功率Input power | kW | 2.3 | 3.8 | 5.6 | 7.5 | 9.4 | 11.3 | 15 |
| 蒸发器Evaporator | 类型Type | 干式壳管式Shell tubular |
| 材质Texture | 高效外螺纹换热铜管Copper tube with external thread |
| 冷冻水流量Chilled water flow | m³/h | 1.6 | 2.6 | 4.3 | 5.5 | 6.9 | 8.2 | 10.8 |
| 冷凝器Condenser | 类型Type | 干式壳管式Shell tubular |
| 材质Texture | 高效内螺纹换热铜管Copper tube with internal thread heat exchange |
| 冷却水流量Cooling water flow | m³/h | 2 | 3.2 | 5.4 | 6.8 | 8.6 | 10.3 | 13.9 |
| 进出口管径 | DN | DN25 | DN40 | DN50 |
| Inport/Outlet pipe caliber | DN | DN25 | DN40 | DN50 |
| 保护装置Safety Device | 压缩机过载保护/压缩机延时启动保护/高低压保护/水泵，风机过载保护/保险丝保护装置/异常报警保护/缺逆相保护/排气过热保护 |
| Compressor overload protection、Compressor delay start protection、High and low pressure protection、Water pump, Fan overload protection、Fuse protection/Abnormal alarm protection、Lack of inverse phase protection、Exhaust overheating protection |
| 外形尺寸Dimensions | 长Length | mm | 600 | 950 | 1260 | 1260 | 1260 | 1600 | 1600 |
| 宽Width | mm | 500 | 500 | 500 | 650 | 650 | 650 | 700 |
| 高Height | mm | 1100 | 1220 | 1220 | 1220 | 1300 | 1300 | 1300 |
| 重量Weight | kg | 130 | 150 | 260 | 280 | 300 | 460 | 520 |
|
|
| 型 号Model | HX-25WT | HX-30WT | HX-35WT | HX-40WT | HX-45WT | HX-50WT | HX-60WT |
| 制冷量Cooling capacity | kW | 78.2 | 95.2 | 108.3 | 125.1 | 139.8 | 155.3 | 186.5 |
| Kcal/h | 67,250 | 81,870 | 93,130 | 107,580 | 120,230 | 133,560 | 160,390 |
| 功率Power | kW | 20.2 | 24.6 | 28.3 | 32.2 | 36.5 | 40.3 | 48.5 |
| 电源Voltage | 3P-380V-50HZ |
| 启动方式Start | 按序延时启动 Sequential delay start |
| 温控范围Operating temperature | 5℃-35℃ Adjustable from 5℃ to 35℃ |
| 控制精度Accuracy | ±1℃ |
| 载冷介质Cooling medium | 水Water（PH≈7） |
| 制冷剂Refrigerant | 型号 | R22（R407C、R404A、R134A） |
| Model |
| 制冷剂流量控制方式Control method | 外平衡感温式热力膨胀阀External balance temperature sensing thermal expansion valve |
| 冲注量Filling amount | Kg | 12.5 | 15 | 17.5 | 20.2 | 22.5 | 25 | 30 |
| 压缩机Compressor | 类型Type | 先进全封闭涡旋式或活塞式Fully enclosed vortex type or spring-piston |
| 启动方式启动方式Start type | 按序延时启动Sequential delay start |
| 输入功率Input power | kW | 18.8 | 22.5 | 26.3 | 30 | 33.8 | 37.5 | 45 |
| 蒸发器Evaporator | 类型Type | 干式壳管式Shell tubular |
| 材质Texture | 高效外螺纹换热铜管Copper tube with external thread |
| 冷冻水流量Chilled water flow | m³/h | 13.6 | 16 | 18.8 | 21.2 | 24.1 | 26.5 | 31.8 |
| 冷凝器Condenser | 类型Type | 干式壳管式Shell tubular |
| 材质Texture | 高效内螺纹换热铜管Copper tube with internal thread heat exchange |
| 冷却水流量Cooling water flow | m³/h | 17.2 | 20.5 | 24 | 27.3 | 30.8 | 34.2 | 40.8 |
| 进出口管径 | DN | DN65 | DN80 |
| Inport/Outlet pipe caliber | DN | DN65 | DN80 |
| 保护装置Safety Device | 压缩机过载保护/压缩机延时启动保护/高低压保护/水泵，风机过载保护/保险丝保护装置/异常报警保护/缺逆相保护/排气过热保护 |
| Compressor overload protection、Compressor delay start protection、High and low pressure protection、Water pump, Fan overload protection、Fuse protection/Abnormal alarm protection、Lack of inverse phase protection、Exhaust overheating protection |
| 外形尺寸Dimensions | 长Length | mm | 1850 | 1850 | 1850 | 2250 | 2250 | 2250 | 2600 |
| 宽Width | mm | 700 | 700 | 700 | 850 | 850 | 850 | 850 |
| 高Height | mm | 1300 | 1360 | 1360 | 1420 | 1420 | 1420 | 1420 |
| 重量Weight | kg | 600 | 850 | 960 | 1050 | 1250 | 1380 | 1550 |
| Note：因篇幅有限，不一一展示，更多型号，请咨询弘星。本公司保留技术更改权力,如有修改恕不另行通知。Due to limited space, we can't show all. For more models, please consult ! The company reserves the right to change the |
|
